CNC/MANUAL
PIPE & TUBE
BENDING,NOTCHING MACHINES

Used to bend tubes and pipes to produce finished parts. Tubes are structural, hollow conduits that are used as flow lines for fluids and gases in pneumatic, hydraulic, medical, and process applications.
Up to MAX. Pipe Diameter ( Ø) 90

Used to bend tubes and pipes to produce finished parts. Tubes are structural, hollow conduits that are used as flow lines for fluids and gases in pneumatic, hydraulic, medical, and process applications.

Up to MAX. Pipe Diameter ( Ø) 120

The pipe end closing machine is equipped with specialized tools and mechanisms that securely close the ends of pipes, ensuring a tight and reliable seal. It can handle a wide range of pipe sizes and materials, providing versatility in applications.

Capacity (mm) 10 -32
Motor Power (kW) 1,5
Machine Weight (kg) 400
Machine Length(mm) 1100
Machine Width (mm) 700
Machine Height (mm) 1250
Features:
Automatic Operation
Pneumatic Pens

Gear Transfer

Used to notch / grind pipe or tube end and longitudinal grooving to prepare the corners joint for welding. The belt grinder arm is hinged to the base, rotating it, the machine can work in two positions: - vertical tape: used to notch / grind pipe or pipe on longitudinal grooving.

Ability to open suitable dovetails according to the pipe and tube diameters with the help of processing drum,
·Ability to tighten and loosen the parts quickly as a result of moving clamp,
·Ability to opening dovetails up to 50° with rotary clamp,
·Clamp is able to move left-right and up-down (Roller System)
Motor Power 2,2 Kw-3000 Circ.
Clamp Capacity Ø17×90 mm.
Breaking Capacity Ø114.3 mm.
Machine Lenght 1000 mm.
Machine Width 600 mm.
Weight 200 kg.
Mandrel 6 pieces
SandBelt 2 pieces

Capacity (mm) 38 - 140

Motor Power (kW - V) 3 - 380

Machine Weight (kg) 360

Machine Length (mm) 1600

Machine Width (mm) 910

Machine Height (mm) 1360

Standart Mandrels (mm) 76-90-114

Tape Dimensions (mm) 150 x 2000

With the processing drum, suitable opening according to the pipe and profile diameter

Angle opening up to 50° with rotating vice

Features:

Vise right-left and forward-backward movement feature (Bearing system)
Opening the notch on the pipe surface with the tilting body

Rotary head that allows working in horizontal and vertical positions
